| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| T5-E 35W | 1 | 35 | -20@187V | 220 | 0.18 | 39 | 10 | 0.99 | 1.7 | 0.95 | n/a |
| T5-E 28W | 1 | 28 | -20@187V | 220 | 0.14 | 31 | 10 | 0.99 | 1.7 | 0.95 | n/a |
| T5-E 21W | 1 | 21 | -20@187V | 220 | 0.10 | 23 | 10 | 0.99 | 1.7 | 0.95 | n/a |
| T5-E 14W | 1 | 14 | -20@187V | 220 | 0.08 | 17 | 10 | 0.98 | 1.7 | 0.95 | n/a |
ACT1S35PS-P
-
-
Line Voltage：220~240Vac 50/60Hz
Safety Voltage: 187~264Vac 50/60Hz
EEI=A2
High Power Factor, Low ATHD Preheat Starting
Auto Reset after Lamp Replacement
Operating Frequency：40~50 kHz RoHS Compliance
Lamp switc
|
 |
|||||||||||||||||||||||||||||||||||||||
