| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| T5 UVC36” | 1 | n/a | -20/-29 | 120 | 0.48 | 58 | 10 | 0.98 | 1.7 | n/a | n/a |
| T5 UVC30” | 2 | n/a | -20/-29 | 120 | 0.40 | 49 | 10 | 0.98 | 1.7 | n/a | n/a |
| NA | 1 | 30-50 | 0/-18 | 120,277 | 0.145-0.24 | 36-60 | 10 | 0.90 | 1.7 | 0.38-0.45 | n/a |
| PPL 36 | 1 | 36 | 0/-18 | 277 | 0.153 | 38 | 10 | 0.90 | 1.7 | 0.38-0.45 | n/a |
ACT1P400PSUNV
-
-
• Line Voltage:120-277V 50/60Hz
• Program Start
• Active Power Factor Correction
• Lamp End of Life Protection
• TYPE CC
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
