Performance
|
Safety
|
|
· Meets ANSI Standard C82.11-2002
|
· No PCB’s
|
|
· Meets ANSI Standard C62.41-2002
|
· UL&cUL listed (Class P, Type 1 Outdoor)
|
|
· Meets FCC 18 Class B for EMI and RFI
|
· OCV 600V
|
|
· Meets Energy Star Version 1.0
|
· TYPE HL
|
|
Application
|
Physical Parameters
|
|
· Remote Mounting: 18 ft. max. Lead length, 18AWG
|
Length
|
9.5″
|
|
· Maximum Ambient Temperature: 131℉,55℃
|
Width
|
1.3″
|
|
· Sound Rated: A
|
Height
|
1.08″
|
|
· Maximum case temperature Tc: 75℃
|
|
|
|
|
Weight
|
0.68lbs
|
|
Lead Length
|
|
|
|
White, Black,
|
25″(±1″)
|
|
|
|
Yellow
|
46″(±1″)
|
|
|
|
Blue,Red
|
31″(±1″)
|
|
|
|
