| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F96T12 | 2 | 75 | 0/-18 | 120 | 1.17 | 137 | 10 | 0.98 | 1.7 | 0.90 | 0.66 |
| F96T12 | 1 | 75 | 0/-18 | 120 | 0.70 | 84 | 10 | 0.98 | 1.7 | 0.95 | 1.13 |
| F96T12 | 2 | 75 | 0/-18 | 277 | 0.50 | 135 | 10 | 0.98 | 1.7 | 0.90 | 0.67 |
| F96T12 | 1 | 75 | 0/-18 | 277 | 0.31 | 83 | 10 | 0.95 | 1.7 | 0.95 | 1.14 |
ACT2P75ISUNV
-
-
•Line Voltage:120V/277V 50/60hz
•Instant Start
•Parallel Lamp Operation
•Active Power Factor Correction
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||
