| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 4 | 32 | 0/-18 | 120 | 0.82 | 98 | 10 | 0.98 | 1.7 | 0.77 | 0.79 |
| F25T8 | 4 | 25 | 0/-18 | 120 | 0.64 | 76 | 10 | 0.98 | 1.7 | 0.78 | 1.02 |
| F32T8 | 4 | 32 | 0/-18 | 277 | 0.55 | 96 | 10 | 0.98 | 1.7 | 0.77 | 0.80 |
| F25T8 | 4 | 25 | 0/-18 | 277 | 0.27 | 74 | 10 | 0.98 | 1.7 | 0.78 | 1.04 |
ACT4P32ISUNVLE
-
-
• Line Voltage:120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
