| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 3 | 32 | 0/-18 | 120 | 0.64 | 76 | 10 | 0.98 | 1.7 | 0.78 | 1.04 |
| F25T8 | 3 | 25 | 0/-18 | 120 | 0.51 | 60 | 10 | 0.98 | 1.7 | 0.82 | 1.34 |
| F32T8 | 3 | 32 | 0/-18 | 277 | 0.27 | 74 | 10 | 0.98 | 1.7 | 0.78 | 1.05 |
| F25T8 | 3 | 25 | 0/-18 | 277 | 0.22 | 58 | 10 | 0.95 | 1.7 | 0.82 | 1.36 |
ACT3P32ISUNVLE
-
-
• Line Voltage：120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
• Meets DOE energy conservation standards
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
