| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 3 | 32 | 0/-18 | 120 | 0.71 | 84 | 10 | 0.98 | 1.7 | 0.88 | 1.05 |
| F25T8 | 3 | 25 | 0/-18 | 120 | 0.56 | 68 | 10 | 0.98 | 1.7 | 0.90 | 1.32 |
| F32T8 | 3 | 32 | 0/-18 | 277 | 0.31 | 83 | 10 | 0.98 | 1.7 | 0.88 | 1.06 |
| F25T8 | 3 | 25 | 0/-18 | 277 | 0.24 | 66 | 15 | 0.97 | 1.7 | 0.90 | 1.38 |
ACT3P32ISUNVE
-
-
• Line Voltage：120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
