| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 2 | 32 | 0/-18 | 120 | 0.46 | 56 | 10 | 0.98 | 1.7 | 0.89 | 1.59 |
| F25T8 | 2 | 25 | 0/-18 | 120 | 0.36 | 42 | 10 | 0.98 | 1.7 | 0.89 | 2.12 |
| F32T8 | 2 | 32 | 0/-18 | 277 | 0.20 | 55 | 10 | 0.97 | 1.7 | 0.89 | 1.60 |
| F25T8 | 2 | 25 | 0/-18 | 277 | 0.16 | 41 | 15 | 0.97 | 1.7 | 0.89 | 2.17 |
ACT2P32ISUNVE
-
-
• Line Voltage:120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
