| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 2 | 32 | -20/-29 | 120 | 0.48 | 57 | 10 | 0.98 | 1.7 | 0.88 | 1.57 |
| FB32T8 | 2 | 32 | -20/-29 | 120 | 0.48 | 57 | 10 | 0.98 | 1.7 | 0.88 | 1.57 |
| F32T8 | 1 | 32 | -20/-29 | 120 | 0.29 | 35 | 10 | 0.98 | 1.7 | 1.08 | 3.10 |
| F32T8 | 2 | 32 | -20/-29 | 277 | 0.21 | 56 | 10 | 0.97 | 1.7 | 0.88 | 1.60 |
| F32T8 | 1 | 32 | -20/-29 | 277 | 0.13 | 34 | 10 | 0.95 | 1.7 | 1.08 | 3.15 |
ACT2S32PSUNVE
-
-
• Line Voltage:120-277V 50/60Hz
• Program Start
• Series Lamp Operation
• Active Power Factor Correction
• Type CC
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
