| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 3 | 32 | 0/-18 | 120 | 0.91 | 108 | 10 | 0.98 | 1.7 | 1.13 | 1.04 |
| F32T8 | 2 | 32 | 0/-18 | 120 | 0.69 | 81 | 10 | 0.98 | 1.7 | 1.22 | 1.51 |
| F32T8 | 3 | 32 | 0/-18 | 277 | 0.39 | 106 | 10 | 0.98 | 1.7 | 1.13 | 1.06 |
| F32T8 | 2 | 32 | 0/-18 | 277 | 0.30 | 80 | 10 | 0.98 | 1.7 | 1.22 | 1.53 |
ACT3P32ISUNVH
-
-
• Line Voltage：120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
• Line Voltage：120-277V 50/60Hz
|
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
