| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 4 | 32 | 0/-18 | 120 | 0.82 | 98 | 10 | 0.98 | 1.7 | 0.74 | 0.76 |
| F32T8 | 3 | 32 | 0/-18 | 120 | 0.68 | 81 | 10 | 0.98 | 1.7 | 0.79 | 0.98 |
| F32T8 | 4 | 32 | 0/-18 | 277 | 0.35 | 96 | 10 | 0.98 | 1.7 | 0.74 | 0.77 |
| F32T8 | 3 | 32 | 0/-18 | 277 | 0.29 | 80 | 10 | 0.98 | 1.7 | 0.79 | 0.99 |
ACT4P32ISUNVL
-
-
• Line Voltage:120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
|
|
