| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F32T8 | 4 | 32 | 0/-18 | 120 | 0.93 | 112 | 10 | 0.98 | 1.7 | 0.88 | 0.8 |
| F32T8 | 3 | 32 | 0/-18 | 120 | 0.77 | 92 | 10 | 0.98 | 1.7 | 0.96 | 1.04 |
| F32T8 | 4 | 32 | 0/-18 | 277 | 0.4 | 108 | 10 | 0.98 | 1.7 | 0.88 | 0.81 |
| F32T8 | 3 | 32 | 0/-18 | 277 | 0.34 | 89 | 10 | 0.98 | 1.7 | 0.96 | 1.07 |
ACT4P32ISUNV
-
-
• Line Voltage:120-277V 50/60Hz
• Instant Start
• Parallel Lamp Operation
• Active Power Factor Correction
• BLE can meet DOE energy conservation standards
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
