| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F54T5/HO | 4 | 54 | 20/-29 | 120 | 1.9 | 228 | 10 | 0.98 | 1.7 | 0.93 | 0.42 |
| F54T5/HO | 3 | 54 | 20/-29 | 120 | 1.5 | 176 | 10 | 0.98 | 1.7 | 1.03 | 0.58 |
| F54T5/HO | 2 | 54 | 20/-29 | 120 | 1.00 | 120 | 10 | 0.98 | 1.7 | 1.00 | 0.83 |
| F54T5/HO | 1 | 54 | 20/-29 | 120 | 0.52 | 62 | 10 | 0.98 | 1.7 | 1.03 | 1.66 |
| F54T5/HO | 4 | 54 | 20/-29 | 277 | 0.81 | 225 | 10 | 0.98 | 1.7 | 0.95 | 0.43 |
| F54T5/HO | 3 | 54 | 20/-29 | 277 | 0.65 | 173 | 10 | 0.92 | 1.7 | 1.03 | 0.59 |
| F54T5/HO | 2 | 54 | 20/-29 | 277 | 0.43 | 117 | 10 | 0.98 | 1.7 | 1.00 | 0.85 |
| F54T5/HO | 1 | 54 | 20/-29 | 277 | 0.25 | 63 | 10 | 0.92 | 1.7 | 1.03 | 1.66 |
ACT4M54PSUNV
-
-
•Line Voltage: 120~277V 50/60Hz
•Program Start
•Hybrid Lamp Operation
•Active Power Factor Correction
•Lamp End of Life Protection
•Type CC
•BLE can meet DOE
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
