| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F28T5 | 2 | 28 | 0/-18 | 120 | 0.475 | 30.5 | 150 | 0.5 | 1.7 | 0.95 | 3.11 |
| F21T5 | 1 | 21 | 0/-18 | 120 | 0.39 | 24.3 | 150 | 0.5 | 1.7 | 1.00 | 4.11 |
| F14T5 | 2 | 14 | 0/-18 | 120 | 0.47 | 30.5 | 150 | 0.5 | 1.7 | 0.95 | 3.11 |
ACT1S28RS120N
-
-
•Line Voltage: 120V 60Hz
•rapid Start
•Series Lamp Operation
•Lamp End of Life Protection
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
