| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F28W T5 | 2 | 28 | 0/-18 | 120 | 0.53 | 64 | 10 | 0.98 | 1.7 | 1.00 | 1.59 |
| F28W T5 | 1 | 28 | 0/-18 | 120 | 0.29 | 33 | 10 | 0.98 | 1.7 | 1.12 | 3.34 |
| F28W T5 | 2 | 28 | 0/-18 | 277 | 0.23 | 63 | 10 | 0.98 | 1.7 | 1.00 | 1.62 |
| F28W T5 | 1 | 28 | 0/-18 | 277 | 0.12 | 34 | 10 | 0.95 | 1.7 | 1.12 | 3.31 |
ACT2S28PSUNV
-
-
• Line Voltage:120-277V 50/60Hz
• Program Start
• Series Lamp Operation
• Active Power Factor Correction
• Type CC
• BLE can meet DOE energy conservation standards
• The energy standards is 0.890
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
