| Lamp Type | Lamp No. | Watts | Min.Start Temp.(F/C) | Vin(V) | Iin(A) | Pin(W) | ATHD≤% | PF≥ | CF≤ | BF | BEF |
|---|---|---|---|---|---|---|---|---|---|---|---|
| T8 36W | 2 | 36w | -15@198V | 220 | 0.30 | 68 | 20 | 0.97 | 1.7 | 1.00 | n/a |
ACT2P36RS-A2
-
-
Line Voltage：220~240Vac 50/60Hz
Safety Voltage: 187~264Vac 50/60Hz
EEI=A2
High Power Factor
Operating Frequency：40~50kHz
Auto Reset after Lamp Replacement
RoHS Compliance
Abnormal Protection
U-out=280V
|
 |
||||||||||||||||||||||||||||||||||||||
